Note: Items below may have to be made to order please allow for lead time. Also available in various types of material and finishes.
Turnbuckles • Rod • Clevis Assemblies
Turnbuckles, Rods, Clevis Nuts, Assembly
( A x L x B x C x D x E x F)
Diameter range: 1/2″ to 4″
Length: any length
Welding required on rods longer than 20 feet
Turnbuckle, Rod Assembly
(A x L x B x C x D x E x F)
Diameter range: 5/16″ to 4″
Length: any length
Welding required on rods longer than 20 feet
Note: Outside ends may be plain or threaded
Turnbuckle Rod & Clevis Nut Assembly (A x L x B x C)
Diameter range: 1/2″ to 4″
Length: any length
Welding required on rods longer than 20 feet
Note: Specify left or right hand thread for each end of rod.
Double End Rod (A x L x T x T)
Diameter range: 1/4″ to 4″
Length: Up to 20′
Welding required on rods longer than 20 feet
Note: The main difference between “Studs” & “Rods” is that studs are chamfered and rods are not, but do have a good starting thread. Also, studs are usually made from cold rolled steel.
All Thread Rod (A x L)
Threaded Rods, Stud Bolts and Studs
Double End Stud Bolt (A x L x T x T)
Diameter range: 1/4″ to 4″
Length: As Required
Note: The main difference between “Studs” & “Rods” is that studs are chamfered and rods are not, but do have a good starting thread. Also, studs are usually made from cold rolled steel.
Continuous Thread Stud (A x L)
Tap End Stud Bolt (A x L x T x T)
Diameter range: 1/2″ to 4″
Length: As Required
Note: Tap End threads shall be American Standard form with wrench tight fit. Nut End threads shall be American Standard.
Special Bent Bolts
J-Bolt
(D x L x C x E x T x M x N)
Diameter range: 1/4″ to 4″
Hook Bolt, Round Bend
(D x L x C x A x T)
Diameter range: 1/4″ to 4″
Hook Bolt, Square Bend
(D x L x C x A x T)
Diameter range: 1/4″ to 4″
Hook Bolt, Right Angle Bend
(D x L x C x T)
Diameter range: 1/4″ to 4″
Hook Bolt, Special Acute Angle Bend
(D x L x C x T x B)
Diameter range: 1/4″ to 4″
B expressed in degrees.
Hook Bolt, Special Obtuse Angle Bend
(D x L x C x T x B)
Diameter range: 1/4″ to 4″
B expressed in degrees.
U-Bolt, Round Bend
(D x L x C x T)
Diameter range: 1/4″ to 4″
U-Bolt, Square Bend
(D x L x C x T)
Diameter range: 1/4″ to 4″
Eye Bolt, Open
(D x L x C x E x T)
Diameter range: 1/4″ to 4″
Eye Bolt, Closed
(D x L x C x T)
Diameter range: 1/4″ to 4″
Note: Welded eyebolt is also available.
