Open-end rivets, when set, resemble conventional tubular rivets. However, unlike tubular rivets, the mandrel is retained within the head.
Providing strong, low-cost fastenings, open-end rivets are ideal for a very wide range of applications. They are available in a variety of materials and combinations with dome, countersunk, or large-flange head styles.
| Rivet Diameter | Grip Range |
|---|---|
| 0.09" | 0.031" - 0.25" |
| 0.13" | 0.031" - 0.5" |
| 0.16" | 0.062" - 0.5" |
| 0.19" | 0.062" - 1" |
| 0.25" | 0.062" - 1" |
Blind Rivets Head Styles
Blind Rivets Materials
Aluminum Rivet — Aluminum Mandrel
Aluminum Rivet — Steel Mandrel
Steel Rivet — Steel Mandrel
Stainless Rivet — Stainless Mandrel
Stainless Rivet — Steel Mandrel
Copper — Plastic — Extra Length
Rivets Are Available
A rivet nut is a tubular rivet with internal threads. It can be installed from one side in seconds.
Once a rivet nut is installed, it is ready to use, with clean threads available for screw attachments.
| 0.25 | 0.31 | 0.25 - 20 | 0.31 - 18 | 0.38 - 16 | |
|---|---|---|---|---|---|
| Flat Head Grip Range | 0.01" - 0.160" | 0.01" - 0.18" | 0.02" - 0.26" | 0.03" - 0.275 | 0.03" - 0.285" |
| Countersunk Grip Range | 0.65" - 0.161" | .065" - 0.216" | 0.089" - 0.271" | 0.106" - 0.331" | 0.125" - 0.381" |
HTS-A – General Duty hand riveting tool for setting blind rivets lo 3/16″ diameter in all steel.
NTX-F – Heavy Duty hand riveting loot for setting blind rivals to 3/16″ diameter in all materials.
HN-I – Rugged lever style riveting tool designed for setting rivets 5/32″ to 1/4″ diameter. (Special nosepiece and head available for T-Rivet)
SN-II – Dependable lazy-tong riveting tool designed for setting rivets 1/8″ to 1/4″ diameter.
PH III-A
PH I-A – Durable Pneumatic / Hydraulic blind riveting tool designed for setting all rivets to 5/32″ diameter.
PH II-A – Pneumatic / Hydraulic blind riveting tool designed for setting all rivets lo 3/16″ diameter.
PH lll·A – Heavy Duly, free standing pneumatic/hydraulic blind riveting tool designed for setting rivets to 1/4″ diameter.
PH-2000 – Light Bodied Pneumatic / Hydraulic blind riveting tool with built-in vacuum absorption system. High speed riveting tool for setting all rivets to 1/4″ dia.
Specials and Standards
Specials made to your exact specifications whether commercial, military, or per your drawing.
Material
